product description
Four Columns Double Ac Hydraulic Press Specification | ||||
Item | Units | Y28-168 | Y28-250 | |
Nominal Force | KN | 1680 | 2500 | |
Main Cylinder Force | KN | 1000 | 1500 | |
Bottom Cylinder Force | KN | 630 | 1000 | |
Ejector Force | KN | 50 | 50 | |
Main Cylinder Stroke | mm | 750 | 500 | |
Bottom Cylinder Stroke | mm | 700 | 500 | |
Ejector Stroke | mm | 100 | 100 | |
Open Height | mm | 1800 | 1200 | |
Worktable Height from Ground | mm | 450 | 450 | |
Main Cylinder Speed | Fast Approach | mm/s | 230 | 230 |
Press | mm/s | 40 | 50 | |
Return | mm/s | 230 | 230 | |
Bottom Cylinder Speed | Eject | mm/s | 60 | 40 |
Return | mm/s | 110 | 100 | |
Worktable Size | Left- Right (Inside post) | mm | 690 | 820 |
Front-Back (Rim) | mm | 630 | 850 | |
Motor Power | KW | 22 | 22 | |
Hydraulic System Pressure | Mpa | 25 | 25 | |
