YF-100CL

YF Series Powder Compacting Hydraulic Press Functions:YF series powder compacting hydraulic press is suitable for all kinds of powder metallurgy and ceramic powder compacting.
Features:1. YF series powder compacting hydraulic press adopts automatic feeding and push-out device, compacting speed fast and high efficiency. 2. Advanced design, compacting structure, easy to maintain.

Availability:
Quantity:
Inquire Add to Basket

YF-100CL
YF-100CL
YF-100CL
YF-100CL
YF-100CL

  • YF-100CL

  • 万达

Product Description

Main technical parameters of YF-100CL:

NO.

Item

Unit

YF-100CL

1

Nominal force

KN

1000(adjustable)

2

Main Cylinder Stroke

mm

300(adjustable)

3

Ejector Force

KN

200(adjustable)

4

Ejector Stroke

mm

200(adjustable)

5

Open height

mm

900

6


speed

fast approach

mm/S

110(adjustable)

press

mm/S

10(adjustable)

Return

mm/S

110(adjustable)

7


Worktable size

LR(inside post)

mm

700

FB(RIM)

mm

700

8

Motor power

KW

7.5

9

Hydraulic system pressure

Main cylinder

MPa

25

ejector

MPa

22
