Main technical parameters
Serial number | project | unit | YSK-300B specifications | YSK-200A specifications |
1 | Nominal pressure | KN | 3000 | 2000 |
2 | Work slider stroke | mm | 150 | 200 |
3 | Workspace opening height | mm | 400 | 500 |
4 | Working slider speed | Get on | Mm/s | 120 | 150 |
suppress | mm/s | / | 22-32 |
Return | Mm/s | 110 | 150 |
5 | Work surface size | Left and right (inside the column) | mm | 580 | 500 |
Front and back (edge) | mm | 600 | 540 |
6 | Maximum ejection force of return cylinder | KN | 50 | / |
7 | Maximum ejection stroke of return cylinder | mm | 20 | / |
8 | Hydraulic system pressure | MPa | 22 | 25 |
9 | Motor power | KW | 7.5 | 22+15=37 |
