YSM-200RS
万达
Product Description
Main technical parameters
Serial number NO. | Project Item | Unit | YSM-100RS Parameter Spec. | YSM-200RS parameters Spec. | |
1 | Nominal force of the master cylinder Master cylinder nominal force | KN | 1000 (Adjustable) | 2000 (Adjustable) | |
2 | Liquid working pressure | MPa | 24.5 | 25 | |
3 | Master cylinder stroke | mm | 500 (Adjustable) | 500 (Adjustable) | |
4 | Bottom cylinder force | KN | 100 (Adjustable) | 100 (Adjustable) | |
5 | Bottom cylinder stroke | mm | 50 (Adjustable) | 80 (Adjustable) | |
6 | Open height | mm | 800 | 800 | |
7 | Master cylinder speed Main cylinder speed | No load down No load down | mm/s | 300 (Adjustable) | 300 (Adjustable) |
Work in | mm/s | 17(Adjustable) | 17(Adjustable) | ||
Return | mm/s | 300 (Adjustable) | 300 (Adjustable) | ||
8 | Bottom cylinder speed Bottom cylinder speed | Ejection | mm/s | 100 (Adjustable) | 180 (Adjustable) |
Return send back | mm/s | 120 (Adjustable) | 180 (Adjustable) | ||
9 | Workbench pad size size of the workbench pad | Left and right LR | mm | 500 | 500 |
Front and rear FB | mm | 500 | 500 | ||
10 | Servo motor power | KW | 13.4 | 26.7 | |
